Docker Overlay2 Cleanup: Reclaim Disk Space Safely (2026)

docker overlay2 cleanup is what you need when /var/lib/docker/overlay2 eats the disk and Docker starts failing writes. This guide shows how to reclaim disk space the safe way: the docker system prune family, container log limits, and one storage-backend checkpoint you should not skip. Since Docker Engine 29, fresh installs store images in /var/lib/containerd instead, so the directory filling your disk may not be overlay2 at all. Below is the full path: identify the backend, measure, prune, fix logs, diagnose leftovers, prevent the regrowth.

Step 0: Which Storage Backend? (overlay2 vs containerd image store)

Before any cleanup, find out where Docker actually keeps its data. This is a read-only check:

docker info -f '{{ .DriverStatus }}'

Two possible outcomes:

• Output contains [[driver-type io.containerd.snapshotter.v1]] → you are on the containerd image store. Your data lives under /var/lib/containerd.
• Output shows a plain overlay2 driver status → you are on the legacy overlay2 store. Your data lives under /var/lib/docker/overlay2.

Docker overlay2 cleanup decision flow: run the docker info driver status command, then branch to the containerd image store or the legacy overlay2 store and watch the matching directory

If you are about to set up a new box and want the current defaults documented end to end, install Docker and Docker Compose on Ubuntu ARM first, then come back here.

# what to watch
du -sh /var/lib/docker/overlay2

# what Docker reports
docker system df

# what to watch
du -sh /var/lib/containerd

# what Docker reports (still authoritative)
docker system df

Verify: paste the real docker info -f '{{ .DriverStatus }}' output into your notes before you prune. You want a baseline of which store is active.

Failure mode: “I pruned overlay2 and nothing was reclaimed.” On a containerd-store host you were looking at the inactive store. Active-store prune commands do not touch the other backend’s data (see the hidden-store section below).

Version context, short: the old world is gone. AuFS and the legacy overlay driver were removed in Engine v24, devicemapper in v25, graphdriver plugins in v28 (official replacement advice: use the containerd image store). Engine v29 requires API v1.44 or newer. If your cleanup notes predate 2023, re-read them before running anything.

What’s Inside /var/lib/docker/overlay2

overlay2 is Docker’s copy-on-write filesystem for Linux. The directory holds:

• Layer directories: content-addressed folders with the actual filesystem diffs
• Container “upperdir” data: the writable layers where containers write files. This is usually what gets big
• Metadata and linkage: structures Docker uses to track which layers belong to which images

The folder names are random hashes, not readable identifiers. You cannot look at a folder name and know what image it belongs to. Use Docker commands instead of guessing from directory names. Docker deliberately keeps this layout undocumented.

On containerd-store hosts the equivalent internals live under /var/lib/containerd as a content store plus overlayfs snapshots. Same rule: measure with Docker commands and du, not by browsing hash folders.

Diagram of where Docker disk space actually lives: overlay2 layers and writable layers, container json logs, volumes, BuildKit cache under /var/lib/docker, plus blobs and snapshots under /var/lib/containerd

That map is worth keeping in your head. The rest of this guide walks each box: measure it, clean it, then stop it from coming back.

Why /var/lib/docker/overlay2 Grows So Large

The directory grows for a handful of predictable reasons:

1. Unused images and containers: stopped containers and old images still occupy space if you do not remove them.
2. Build cache: Docker caches layers to make builds faster. On a box that builds often, this cache is the top offender.
3. Large images and containers: some images ship big binaries or data files. Four copies of a 1.5 GB base image add up.
4. Inefficient image layers: images with too many layers or leftover build junk waste space. If you control the Dockerfile, copy multiple files in one layer with a Docker COPY instead of stacking one COPY per file.
5. Unbounded container logs: this is the sneaky one. The json-file log driver grows without limit by default, and the files are not in overlay2. They live in /var/lib/docker/containers/. There is a dedicated section below.

On containerd-store hosts, add one more: blobs plus unpacked snapshots make the same image set cost more disk than the legacy store.

If you want to see which category is actually growing over time, monitor server and Docker resources (CPU, memory, disk) rather than running du by hand every week.

Ops note: a full filesystem does not fail only Docker pulls. Database containers lose writes too, and some of those failures are silent until the app errors. Target 15-20% free space on any host that runs stateful containers.

Check Docker Disk Usage First

Do this before touching anything. It is read-only.

docker system df
docker system df -v

docker system df shows space usage for images, containers, volumes, and build cache. The -v flag adds per-object detail. For monitoring scripts, add --format json (or a Go template) so you can parse it instead of scraping tables.

Then check the real filesystem:

df -h /var/lib/docker
du -sh /var/lib/docker/overlay2 /var/lib/docker/containers /var/lib/containerd 2>/dev/null

To see which overlay2 subdirectories are largest, just for investigation, never for deletion:

du -sh /var/lib/docker/overlay2/* 2>/dev/null | sort -hr | head -10

How to read the output:

• Large overlay2 usage usually means container writes or build cache, not just unused images.
• Focus on the growing category in docker system df -v (images, containers, volumes, build cache), not on specific IDs.
• Save the docker system df -v output before cleanup. That is your baseline; you will compare against it after.

Symptom → likely cause → first command

Docker Overlay2 Cleanup: The Prune Playbook

This is the ordered, safest-first cleanup. Each command states what it removes. Run one, check docker system df, then decide if you need the next. That is slower than firing everything at once and much easier to explain when something you wanted disappears.

Quick Win: docker system prune (and -a)

Start with the read-only report again so the numbers are fresh:

docker system df -v

Remove stopped containers, unused networks, dangling images, and build cache:

docker system prune -f

What this does: clears objects nothing references. What it will not do: touch named volumes, and it keeps images that some container (even a stopped one) still points at.

If you also want to remove all images not used by any container, which is the more aggressive step:

docker system prune -a -f

Failure mode: -a removes images that a stopped-but-wanted container needs on its next start. Nothing is corrupted, but you pay the re-pull time at the worst moment. On hosts with containers you keep around for rollback, skip -a or run it inside a maintenance window.

For scheduled housekeeping on build boxes, filters keep the prune honest:

docker system prune -af --filter until=168h

until= accepts RFC3339 timestamps, dates, or Go durations like 10m and 24h. label= selects by label. Multiple filters across different keys are ANDed. A weekly cron with until=168h is a boring, reliable default for CI runners.

If you want the full teardown playbook for images, volumes, networks, and disks, see how to clean all Docker images with disks and everything.

Verify: docker system df after each command. On containerd-store hosts, note that older Engine 29 builds under-reported reclaimed space because they ignored unpacked image data (moby#52905, fixed in a later v29 patch). Confusing numbers there were a bug, not your mistake.

Volumes: Anonymous vs Named (docker volume prune -a)

This is the part older guides get wrong, and it is why people search for “docker volume prune not reclaiming space”.

Since Docker Engine 23.0 / API 1.42, docker volume prune removes anonymous volumes only. Named volumes need the -a flag:

docker volume prune -f        # anonymous volumes only
docker volume prune -a -f     # ALSO unused named volumes, check first!

Same caveat for docker system prune --volumes: the official warning says it removes “all anonymous volumes not used by at least one container”. Named volumes survive.

Check before you delete anything:

docker volume ls
docker system df -v

Verify: docker volume ls before, docker system df after. If the volumes row barely moved after docker volume prune -f, that is expected: your space is in named volumes, and only -a will reclaim them.

Build Cache: docker builder prune with Capacity Caps

If you build images on the host, BuildKit cache is often the biggest single category. Prune it directly:

docker builder prune -f       # dangling cache
docker builder prune -af      # all unused cache

Newer buildx (v0.38.0 as of 2026-10) adds capacity caps, which are better than waiting for disk-full alarms:

docker builder prune -f --max-used-space 10gb    # LRU-evict down to 10 GB
docker builder prune -f --min-free-space 20gb    # keep 20 GB free on the filesystem
docker builder prune -f --reserved-space 5gb     # never evict the last 5 GB of cache
docker builder prune -f --filter until=168h      # cache older than 7 days
docker buildx prune -a --max-used-space 10gb     # also internal/frontend images

Sizes are human-readable and case-insensitive (10gb, 500MB). Filters include type=, type!=exec.cachemount (keep cache mounts, usually what you want), until=, description=, and parent=. Multiple --filter flags are ANDed.

If you self-host CI, self-host your Git and CI/CD with Forgejo and Woodpecker CI and put the --max-used-space prune in a weekly timer on the runner. That is where build cache goes feral.

Failure mode: unknown flag: --keep-storage. Older tutorials use it; the current buildx prune options table does not list it. Run docker builder prune --help on your host and use whatever capacity flag your version actually has (--max-used-space on recent buildx). Reclaiming nothing on a fresh box is normal, not a bug.

Verify:

docker builder prune --help | grep -E 'max-used|keep-storage'

Then re-run docker system df and compare the Build Cache row against your baseline.

The Real Disk Killer: Docker Container Logs

Container logs are the disk problem that no overlay2 cleanup will fix. The default json-file log driver writes to /var/lib/docker/containers/<id>/<id>-json.log and grows without limit (max-size defaults to -1, max-file to 1). A chatty app on a small VPS can fill the disk in days while docker system df looks almost clean.

Find the offenders:

du -sh /var/lib/docker/containers/* 2>/dev/null | sort -hr | head
docker ps -s

docker ps -s shows each container’s writable layer size, which tells you whether the bloat is logs or app writes.

truncate -s 0 /var/lib/docker/containers/*/*-json.log

{
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "10m",
    "max-file": "3"
  }
}

sudo systemctl restart docker

If you would rather ship logs somewhere central than rotate them locally, redirect Docker logs to a single file with a different log driver.

Verify:

du -sh /var/lib/docker/containers
docker inspect <container> --format '{{ json .HostConfig.LogConfig }}'

A new container should show "max-size":"10m" and "max-file":"3".

Failure mode: you edited daemon.json, restarted Docker, and logs keep growing. The old containers were never recreated. Check docker inspect on one of them; if the log config is still empty, the file was not re-read for that container.

Map overlay2 Directories to Docker Objects

Sometimes you need to know which container owns a giant writable layer. Use Docker’s own output before any scripting:

docker ps -s
docker inspect -f '{{ .Name }} {{ .GraphDriver.Data.UpperDir }}' $(docker ps -aq)

GraphDriver.Data.UpperDir is the writable-layer path straight from docker inspect. That is a supported mapping, and it is the fastest way to match a huge directory to a container name.

For images versus layer directories, I have a helper script that visualizes overlay2 disk usage:

curl -sSL https://utils.bitdoze.com/scripts/docker-overlay2-view.sh | bash

All scripts are at utils.bitdoze.com.

Why overlay2 Subfolders Don’t Match Image IDs

You pruned everything and there are still hash directories that match no image. Normal. Here is why:

1. Container writable layers: running or stopped containers each have a writable layer in overlay2. If you have containers, you have overlay data.
2. Build cache: modern builds (BuildKit) create cache data. docker system prune -a does not always remove all of it. Target it with docker builder prune.
3. Shared or referenced layers: images share layers, and Docker will not remove anything still referenced. The directory name will not match what you see in docker image ls.
4. Init layers and internal metadata: the *-init directories and metadata structures are part of how Docker sets up containers.
5. Leaked or orphaned data (rare): power loss, daemon crashes, or storage corruption can leave leftovers. Check docker system df -v and the daemon logs before assuming this is your case.
6. Hidden legacy store after a backend switch: this one is new. If you moved to the containerd image store (or the reverse), the inactive store’s data stays on disk but is invisible to the active store’s prune commands. Prune reports nothing to reclaim while df shows a full disk. Detect it with docker info -f '{{ .DriverStatus }}' and compare against du -sh /var/lib/docker/overlay2 /var/lib/containerd.

Even if a directory looks unused, deleting overlay2 directories by hand can corrupt Docker’s state. If you genuinely need a fresh start, do the controlled reset below with Docker stopped and your data backed up.

Prevent /var/lib/docker/overlay2 From Filling Up Again

Cleanup is a one-time win. These five habits keep the disk healthy:

1. Cap log size. The daemon.json log-opts from the logs section are the highest-leverage change on any host that runs chatty containers.
2. Schedule housekeeping on build boxes. A weekly timer beats a disk-full alarm:

docker system prune -af --filter until=168h
docker builder prune -af --max-used-space 10gb

3. Move Docker’s data dir to a bigger volume. Small root disks are the usual reason Docker fills the OS partition. In /etc/docker/daemon.json:

{
  "data-root": "/mnt/volume/docker"
}

The flag is --data-root on the dockerd command line too (the old -g/--graph flags were removed in Engine v23). If the box needs the hardware, add a new drive to Ubuntu LVM and mount it permanently first. On Hetzner-style VPS boxes where the root disk is small and a separate volume is cheap, Hetzner’s cost-optimized cloud plans pair well with this setup, and a Hetzner Cloud VPS with a mounted volume solves the “Docker ate the OS disk” problem without moving data around later. A Hostinger VPS with NVMe storage is the alternative if you want one big local disk instead. Storage headroom is cheaper than downtime.

Warning: data-root does not migrate existing data. Plan a copy or move with the daemon stopped, then verify with docker info | grep 'Docker Root Dir' before you delete anything from the old path.

4. Alert on filesystem usage. Keep 15-20% free and get paged before 80%, not after writes fail. Set up Beszel and Uptime Kuma for server monitoring and disk alerts if you want a self-hosted path.
5. Stay patched. Engine 29.x patches have included both the prune under-reporting fix and a BuildKit cache-poisoning fix (GHSA-p3rc-w3hc-pqvv, February 2026): a malicious cache image or remote cache can inject false build cache into your builds. That one hits anyone importing build cache, not just containerd-store users. Security fixes land in patch releases; run them.

Verify after any data-root change:

systemctl status docker
docker info | grep 'Docker Root Dir'

Failure mode: a typo in daemon.json (a number where a string is required, a missing comma) keeps dockerd from starting. journalctl -u docker shows the parse error. Keep a copy of the last working file before editing.

Last Resort: Controlled Docker Reset (Both Stores)

Verify: df -h before and after, docker info shows a fresh root dir, and a test container starts (docker run --rm alpine echo ok). Only then schedule the .bak cleanup.

FAQ: Docker Overlay2 Cleanup Questions

Summary

A growing /var/lib/docker/overlay2 (or /var/lib/containerd on Engine 29 hosts) comes down to four things: unused objects, build cache, writable-layer writes, and unbounded container logs. Do the docker overlay2 cleanup in that order of blame: run docker system df -v, prune with the supported commands (remember named volumes need docker volume prune -a), cap your logs with log-opts, and schedule housekeeping instead of waiting for the disk-full alarm.

Do not delete anything inside those directories by hand. If you reach the point where prune has nothing left to give and the disk is still full, do the controlled reset with the daemon stopped and backups in place.
